Screen Technics ElectriCinema Premium Motorised Screen

Screen Technics ElectriCinema Premium Motorised Screen

Premium Australian-Made Motorised Projection Screen with Integrated Connect Control and Universal Bracket System

The Screen Technics ElectriCinema Premium Motorised Screen is designed as a higher-end motorised projection screen solution for home cinema, education, corporate and commercial AV installs. Screen Technics describes it as the premium projection screen of choice in the AV industry, built around rugged design, contemporary styling and straightforward installation using its universal bracket system.

This is a broad-range motorised screen platform rather than a single fixed-size product. Screen Technics offers the ElectriCinema in multiple types spanning 72 inches to 375 inches diagonal, with different roller sizes, screen surfaces and bracket arrangements depending on model size.

Premium Motorised Screen Platform

Built to cover everything from smaller rooms to serious large-format installs

One of the big strengths of the ElectriCinema range is that it scales properly. Screen Technics divides the lineup into Type A, B, C, D and E, covering sizes from 72" to 375" diagonal. Smaller models cover more common residential and classroom sizes, while the larger models push into genuinely big projection screen territory.

• Home cinema rooms
• Education installs
• Corporate presentation spaces
• Government and hospitality AV rooms
• Worship and theatre environments

Integrated Connect Control

Built for proper system integration

Screen Technics lists the ElectriCinema with its Integrated Connect Control platform. Across the range, official features include IP control, IR, contact closure, 12V trigger, and the ability to link and group switch with other Connect control devices.

That is exactly what you want in a premium motorised screen because it makes the screen easier to integrate into a proper AV system rather than treating it like a basic standalone accessory.

Multiple Surface Options

Match the screen material to the room and projector

The ElectriCinema range is available with multiple projection surface options depending on type and size. Official Screen Technics listings include:

• Unity White black backed fibreglass – Gain 1.1
• Hi Contrast Grey black backed fibreglass – Gain 0.8
• Ember Grey fibreglass – Gain 0.8
• Seamless Unity White black backed fibreglass – Gain 1.0 up to 180"
• Unity White PVC – Gain 1.0 above 180"
• Fire rated welded Unity White projection surface – Gain 1.0

That gives the range useful flexibility depending on ambient light conditions, projector brightness and room type. Screen Technics specifically notes that Hi Contrast Grey helps when full control of ambient light is not available by shifting perceived contrast darker.

Universal Bracket System

Easier wall or ceiling installation

Screen Technics repeatedly lists a universal wall / ceiling bracket with full width adjustability on Types A, B and C. This is one of the practical reasons the ElectriCinema range has such a strong installer-focused brief.

For larger Type D and E models, Screen Technics moves to load-rated M10 eyebolts, which makes sense once the screens get into much heavier large-format territory.

Heavy Duty Roller Design

Roller size increases as screen size increases

• Type A: 51mm heavy duty roller
• Type B: 80mm heavy duty roller
• Type C: 110mm heavy duty roller
• Type D: 150mm heavy duty roller
• Type E: 225mm heavy duty roller

That is important because roller diameter has a direct impact on how well a motorised screen behaves over time, especially when the screen gets larger. Screen Technics specifically references enhanced lay-flat qualities in these roller selections.

Australian-Made Installation Detail

Thoughtful design touches for real-world installers

• Power located at the opposite end of the headbox from low-voltage control
• C Tick certified Australian-made product
• White standard headbox with black optional on smaller types
• Custom powder coat colours available on large Type D and E models

These are the sorts of details that matter once a product is actually being installed rather than simply looked at in a brochure.

Large Format Options and Border Control

More advanced configuration on bigger models

• 50mm sides and bottom borders
• Adjustable top black leader
• Extra top masking option
• RF RTS remote or 4 core wall switch options
• 240V single phase 4A power requirement

That makes the bigger ElectriCinema models much more appropriate for dedicated cinema and presentation environments where final image geometry and installation finish matter more.

Specifications

Specifications above are taken from Screen Technics’ official ElectriCinema Premium page.

Detailed Technical Specifications

For those who like to see exactly how it’s built and how it works

The Audio Experts Take

The ElectriCinema Premium makes sense because it is not pretending to be a one-size-fits-all motorised screen. It is a proper range with different hardware, surfaces and mounting approaches depending on the screen size and application. That is exactly what you want from a serious projection screen platform.

For customers building anything from a neat home cinema through to a much larger presentation or theatre environment, the big strengths here are integration, Australian-made build quality and a size range that goes from everyday residential formats right through to huge commercial-scale screens.
