Ortofon Cadenza Bronze MC Cartridge

Ortofon Cadenza Bronze MC Cartridge

Vendor

Ortofon

Type

Cartridge

This product is available.
Quantity must be 1 or more
Regular price
$3,299.00
Sale price
$3,299.00

Ortofon HiFI MC Cadenza Bronze MC Cartridge

The Cadenza Bronze model is using a Replicant 100 stylus and a conical aluminium cantilever. The coil wire is the famous Ortofon Aucurum wire, which is a gold plated 6NX copper wire. The Field Stabilizing Element (FSE), is used for optimal linearity especially during complex crescendo passages.

Cadenza Bronze is a true high-end reference cartridge, conveying music with supreme precision, impact and dynamics. Its stereo imaging capabilities illuminate the farthest corners of the soundstage in all three dimensions.

Technical data

|
---|---
Output voltage at 1000 Hz, 5cm/sec. | 0,4 mV
Channel balance at 1 kHz | < 1 dB
Channel separation at 1 kHz | > 24 dB
Channel separation at 15 kHz | > 20 dB
Frequency range at - 3dB | 20 - 55 kHz
Frequency response 20 Hz - 20 kHz | +/-1,5
Tracking ability at 315Hz at recommended tracking force *) | 80 µm
Compliance, dynamic, lateral | 12 µm/mN
Stylus type | Nude Ortofon Replicant on conical alu cantilever
Stylus tip radius | r/R 5/100 µm
Tracking force range | 2,2-2,7 g (22-27 mN)
Tracking force, recommended | 2,5 g (25 mN)
Tracking angle | 23°
Internal impedance, DC resistance | 5 Ohm
Recommended load impedance | 50-200 Ohm
Cartridge body material | Stainless steel / Aluminium
Cartridge colour | Bronze/Black
Cartridge weight | 10,7 gram
