Description
Monitor Audio Creator Series W1M-E In-Wall Medium Speaker
Entry-level medium Creator Series in-wall speaker with a 5-inch C-CAM bass-mid driver and C-CAM tweeter for straightforward architectural music and surround systems.
W1M-E is the simpler medium in-wall model in the Creator range. It is a practical choice for surround channels, secondary rooms and distributed-audio zones where a clean installation matters but the higher-output multi-driver Creator models are unnecessary.
Installation and System Planning
If the speaker will be used as a main stereo pair or front cinema channel in a larger room, it is worth comparing the W1M or Tier 2 models before the wall is cut. The physical installation is the expensive part to redo later.
Key Features
- Brand: Monitor Audio
- Series: Creator Series
- Tier: Tier 1
- System Format: 2-Way
- Channels: 1
Specifications
| Specification | Details |
|---|---|
| Brand | Monitor Audio |
| Model | W1M-E |
| Product Type | In-Wall Speaker |
| Series | Creator Series |
| Tier | Tier 1 |
| System Format | 2-Way |
| Channels | 1 |
| Frequency Response, Installed (-6dB) | 40Hz – 30kHz |
| Nominal Impedance | 8 ohm |
| Minimum Impedance (20Hz to 20kHz) | 6.5 Ohm @ 200Hz / 6.2 Ohm @ 20kHz |
| Sensitivity (2.83Vrms@1m, Installed) | 84dB |
| Maximum Peak SPL | 110dB |
| Continuous Power Handling | 50W |
| Recommended Amplifier Power | 25–100W |
| Drive Unit Complement | 1 x 5-inch (127mm) C-CAM mid-bass driver, 1 x 1-inch (25mm) C-CAM tweeter |
| Crossover Frequency | LF/HF: 2.5kHz |
| Mounting Depth | 85mm |
| Cut-Out Dimensions | 527 x 198mm |
| External Dimensions (Including Grille) | 560 x 231 x 90mm |
| Weight | 2.6kg each |
| Pre-Construction Bracket | WM-B |
| Cabinet Finish | Matte black & Orange |
| Sold As | Single Unit |
| Warranty | Contact The Audio Experts for current Australian warranty details |
Detailed Technical Specifications
For those who like to drag out all the useful bits
View full technical specifications
Core Design
- In-wall speaker
- Creator Series
- Tier 1 architectural speaker
- 2-way system format
- Medium-format in-wall design
Driver Configuration
- 1 x 5-inch (127mm) C-CAM mid-bass driver
- 1 x 1-inch (25mm) C-CAM tweeter
- UD Waveguide integration
Performance
- Frequency response, installed (-6dB): 40Hz – 30kHz
- Nominal impedance: 8 ohm
- Minimum impedance: 6.5 Ohm at 200Hz 6.2 Ohm at 20kHz
- Sensitivity: 84dB
- Maximum peak SPL: 110dB
- Continuous power handling: 50W
- Recommended amplifier power: 25–100W
- Crossover frequency: LF/HF: 2.5kHz
Installation
- Quik-Link speaker cable connector
- Tri-Grip II fixing system
- Mounting depth: 85mm
- Cut-out dimensions: 527 x 198mm
- External dimensions including grille: 560 x 231 x 90mm
- Pre-construction bracket: WM-B
Accessories
- WM-B Pre-Construction Bracket
- WM-BOX
Finish and Warranty
- Cabinet finish: Matte black & Orange
- Sold as a single unit
- Warranty: contact The Audio Experts for current Australian terms
The Audio Experts Take
The W1M-E is the Creator Series choice for a straightforward in-wall system where budget and ease of installation matter. It suits background music, surround duties and simpler stereo zones, while the higher Creator tiers are the better place to look for a main listening room. Check the wall cavity and speaker positions before ordering, and ask us if you want the layout reviewed.
Brand new. Contact us for current availability, installation advice, and amplifier matching guidance.
