A high-performance 7.2 channel AV receiver with 100 watts per channel amplification, Dolby Atmos, DTS:X, 8K Ultra HD, and HEOS built-in streaming. CINEMA 60 is the new standard of foundational luxury home theatre.
Specifications
| Power Amplifier | |
| Number of Powered Channels | 7 |
| Power Output (8 Ohm, 20 Hz - 20 kHz, 0.08% THD, 2 Ch Driven) | 100 W |
| Power Output (6 Ohm, 1 kHz, 0.7% THD, 2 Ch Driven) | 140 W |
| Power Output (6 Ohm, 1 kHz, 10% THD, 1 Ch Driven) | 200 W |
| 70% Guarantee | Yes |
| Discrete Power Amplifier | Yes |
| Amplifier Topology | Class A/B |
| Current Feedback Topology | Yes |
| Multichannel Surround Technologies | |
| DTS | DTS-HD Master, DTS:X, DTS Neural:X, DTS Virtual:X |
| Dolby | Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music, Dolby Surround |
| Max Number of Processing (Preamp) Channels | 7.2 |
| Inputs / Outputs | |
| Composite In / Out | 0 / 0 |
| Component In / Out | 0 / 0 |
| HDMI In / Out | 6 / 2 |
| Multi-Room Video Out via HDMI | No |
| Analogue In / Fixed Level Out | 4 / 0 |
| Phono (MM) In | Yes |
| Digital In: Optical / Coaxial | 2 / 2 |
| Multi-Room Out: Analogue / Digital | 1 / 0 |
| Multichannel Pre-Out | 7.2 |
| Subwoofer Out | 2 |
| 7.1 Multichannel Input | No |
| Number of Speaker Terminals | 7 |
| Speaker A / B | Assignable |
| Bi-Amp Drive | Assignable |
| Multi-Room Speaker Terminal | Assignable |
| Front Inputs | USB-A |
| USB Audio / Made for iPod / Made for iPhone | Yes / No / No |
| FM Tuner with RDS | Yes |
| DAB+ tuner | No |
| HDMI | |
| Total HDMI Inputs / No. Support 8K | 6 / 3 |
| HDCP 2.3 support | Yes |
| HDMI Outputs: Main / Zone | 2 / 1 |
| Analogue to HDMI Video Conversion | No |
| HDMI Upscaling | 1080p/4K to 8K |
| Audio Return Channel | eARC |
| Video Dynamic Range | HDR, HLG, Dolby Vision, HDR10+, Dynamic HDR |
| ALLM (Auto Low Latency Mode) Pass-Through for Gaming | Yes |
| Variable Refresh Rate / Quick Frame Transport | Yes / Yes |
| HDMI Pass-Through in Standby Mode | Yes |
| CEC | Yes |
| DSD Audio over HDMI | No |
| Auto LipSync | Yes |
| Performance Technologies | |
| Copper Plated Chassis | No |
| Toroidal Power Supply Transformer | No |
| Hyper Dynamic Amplifier Modules (HDAM) | Yes |
| Pure Direct Mode | Yes |
| Gold Plated RCA Terminals | Yes |
| Clock Jitter Reducer | No |
| Acoustic Room Correction | |
| Audyssey | MultEQ XT |
| Audyssey Dynamic EQ / Dynamic Volume | Yes / Yes |
| Audyssey LFC | No |
| Dirac Live Support | No |
| Variable Cross Over | Yes |
| Optimised Bass Redirection | Yes |
| Bass Sync | No |
| Music File Support | |
| Lossy Formats | MP3, WMA, AAC |
| Lossless Formats | FLAC HD 192/24, WAV 192/24, ALAC 192/31 |
| DSD Audio | 2.8 MHz / 5.6 MHz |
| Gapless Playback | FLAC, WAV, ALAC, DSD |
| Compressed Audio Enhancer: MDAX2 | Yes |
| Network Audio Sharing | Yes |
| Streaming Services | |
| HEOS Multi-Room and Streaming | Yes |
| AirPlay Audio Streaming | AirPlay 2 |
| Internet Radio | TuneIn |
| Spotify | Spotify Connect |
| Pandora | Yes |
| SiriusXM | Yes |
| Other Streaming Services | Amazon Music HD, Amazon Music, TIDAL, Deezer, Napster, Soundcloud, Mood Mix |
| Roon Tested | Yes |
| Network Connectivity | |
| Ethernet Ports | Yes |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| Bluetooth Re-Transmit for Bluetooth Headphones | Yes |
| Smart Home Integration and Control | |
| Voice Assistant Compatibility | Alexa, Google Voice Assistant, Apple HomePod |
| App for Smart Phones & Tablets (iOS & Android) | Marantz AVR App |
| HEOS Multi-Room Integrated | Yes |
| HEOS Link Compatibility: IR / IP | Yes / Yes |
| Multi-Room Zones | 2 |
| Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analogue | Yes (2 Ch) / Yes (2 Ch) / Yes / Yes |
| Zone Audio Output: Speaker / Preout | Yes / Yes |
| Zone HDMI Output from HDMI Source | Yes |
| Control Connectivity | IP Control, RS232 Control, Web Control, App Control |
| IR Flasher In | Yes |
| Marantz Remote Bus | Yes |
| DC Trigger Output | 1 |
| HDMI Diagnostics | Yes |
| Others | |
| Front Display | Port Hole OLED |
| GUI Languages | 9 |
| Setup Assistant | Yes |
| Smart Select on Remote | Yes |
| Firmware Update by Network / USB | Yes / Yes |
| ECO Mode | Yes |
| Auto Power off | Yes |
| Sleep / Timer | Yes |
| General | |
| Available Colours | Black |
| Metal Front Panel | No |
| System Remote Control | RC-049SR |
| Power Consumption | 650 W |
| Power Consumption No-Sound (ECO On/Off) | 45 W / 75 W |
| Standby Consumption | 0.2 W |
| CEC Standby Consumption | 0.5 W |
| Network Standby Consumption | Less Than 2.0 W |
| Dimensions - Antenna: Horizontal (W x D x H) | 442 x 354 x 165 mm |
| Dimensions - Antenna: Vertical (W x D x H) | 442 x 354 x 235 mm |
| Dimensions - No Antenna (W x D x H) | 442 x 343 x 165 mm |
| Weight | 11 kg |
