Reference 15.4 Channel Balanced Processor with Dolby Atmos, DTS:X Pro, Auro-3D, IMAX Enhanced and 8K Ultra HD, and HEOS® Built-In streaming. AV 10 is a reference-level AV processor.
The AV 10 represents the pinnacle of performance and performance for reference-class home theater systems. It features legendary Marantz discrete HDAM circuitry, seven 8K UHD-compatible HDMI inputs, HEOS® Built-in, room acoustics correction with Audyssey MultEQ XT32, Dolby Atmos and DTS:X Pro, Auro-3D, as well as multiple inputs and balanced preamp outputs for all channels and four independent subwoofers.
- Detailed and captivating sound for a special listening experience.
- 17.4 channel output supports flexible speaker layouts.
- Decodes Dolby Atmos, DTS:X Audio and Auro 3D.
- Seven HDMI inputs (all 8K) and three outputs for full-resolution video.
- HEOS® Built-in lets you stream music from your favourite sources over WiFi.
- Tuned by the Soundmaster for warm, rich and detailed sound.
Specifications
| Multichannel Surround |
| DTS-HD Master / DTS:X / DTS:X Pro |
Yes / Yes / Yes |
| DTS Neo:X / DTS Neural:X |
No / Yes (15 Ch) |
| DTS Virtual:X |
Yes |
| IMAX Enhanced |
Yes |
| Dolby TrueHD / Dolby Atmos / Dolby Atmos Height Virtualization / Dolby Atmos Music |
Yes / Yes / Yes / Yes |
| Dolby ProLogic Ilz / Dolby Surround |
No / Yes |
| Auro 3D |
Yes |
| 360 Reality Audio / MPEG-H |
Yes / Yes |
| Multichannel Stereo |
Yes |
| Max Number of Processing (Preamp) Channels |
15.4 |
| Sound Enhancements |
| Copper Plated Chassis |
Yes |
| Power Transformer: Toroidal / EI |
Yes / No |
| Current Feedback Topology |
Yes |
| Hyper Dynamic Amplifier Modules (HDAM) |
Yes |
| Pure Direct |
Yes |
| Gold Plated RCA Terminals |
Yes |
| Clock Jitter Reducer |
Yes |
| Audyssey |
MultEQ XT32 |
| Audyssey Dynamic EQ / Dynamic Volume |
Yes / Yes |
| Audyssey LFC |
Yes |
| Dirac Live Upgradability |
Yes |
| Compressed Audio Enhancer: MDAX2 |
Yes |
| Network |
| HEOS Multi-Room and Streaming |
Yes |
| Bluetooth Re-Transmit for Bluetooth headphones |
Yes |
| Alexa / Google Voice Assistant / Apple HomePod |
Yes / Yes / Yes |
| Network Audio Sharing |
Yes |
| Lossy Formats: MP3 / WMA / AAC |
Yes / Yes / Yes |
| Lossless Formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24 |
Yes / Yes / Yes |
| DSD Audio Streaming |
Yes (2.8/5.6 MHz) |
| Gapless Playback |
Yes (FLAC, WAV, ALAC, DSD) |
| AirPlay Audio Streaming |
Yes (AirPlay2) |
| Internet Radio |
Yes (TuneIn) |
| Spotify |
Yes (connect) |
| Pandora |
Yes |
| SiriusXM |
Yes |
| Other Streaming Services |
Amazon Music HD, Amazon Music, TIDAL, Deezer, iHeart Radio, Napster, Soundcloud, Mood Mix |
| Roon Tested |
Yes |
| Compatible with Remote App for Smart Phones |
Marantz 2016 AVR Remote |
| Compatible with Remote App for Tablets |
Android / iOS / Amazon Kindle |
| Ethernet Ports |
Yes |
| Wi-Fi |
Yes |
| Bluetooth |
Yes |
| HDMI |
| HDMI Inputs: Back / Front |
7 / No |
| HDCP2.3 support |
Yes |
| HDMI Outputs: Main / Zone |
2 / 1 |
| HDMI to HDMI Scaling |
1080p/4K to 8K |
| GUI Overlay on HDMI |
Yes |
| HDMI 2.1: 8K/60 Hz AB / 4K/120 Hz AB |
Yes / Yes |
| 8K/60 Hz AB / 4K/120 Hz AB Pass-Through In/Out |
7 / 2 (Up to 40 Gbps) |
| HDMI 2.0: 3D / 4K / CEC / eARC |
Yes / Yes / Yes / Yes |
| HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR |
Yes / Yes / Yes / Yes / Yes |
| ALLM (Auto Low Latency Mode) Pass-Through for Gaming |
Yes |
| Variable Refresh Rate / Quick Frame Transport / Quick Media Switching |
Yes / Yes / No |
| 8K Signal Pass-Through / 4K Signal Pass-Through |
Yes / Yes |
| HDMI Pass-Through in Standby Mode |
Yes |
| Picture Adjust / Noise Reduction |
No / No |
| Auto LipSync |
Yes |
| Multi-Room / CI |
| HEOS Multi-Room Integrated |
Yes |
| HEOS Link Compatibility: IR / IP |
Yes / Yes |
| Multi-Room Zones |
3 |
| Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analogue |
Yes (2 Ch) / Yes (2 Ch) / Yes / Yes |
| Zone Audio Output: Speaker / Preout |
No / Yes |
| Zone HDMI Output from HDMI Source |
Yes |
| IP Control / RS232 Control / Web Control / App Control |
Yes / Yes / Yes / Yes |
| IR Flasher In |
Yes |
| Marantz Remote Bus |
Yes |
| DC Trigger Output |
2 |
| HDMI Diagnostics |
Yes |
| Others |
| Auto Speaker Setup by Microphone |
Audyssey MultEQ XT32, Dirac Live (Upgrade) |
| Front Display |
2 Line FLD + Port Hole OLED |
| Graphic User Interface - GUI |
Modern HD GUI |
| GUI Languages |
3 |
| Setup Assistent |
Yes |
| Smart Select |
Yes |
| Firmware Update by Network / USB |
Yes / Yes |
| Variable Cross Over |
Yes |
| Optimised Bass Redirection |
Yes |
| Bass Sync |
Yes |
| Auto Power Off |
Yes |
| Sleep Timer |
Yes |
| Inputs / Outputs |
| Composite In / Out |
No / No |
| Component In / Out |
No / No |
| HDMI In / Out |
7 / 3 |
| Multi-Room Video Out: Video / HDMI |
No / Yes |
| Analogue In / Out |
5 (1 x XLR) / No |
| Phono (MM) In |
Yes |
| Digital In: Optical / Coaxial |
2 / 2 |
| Multi-Room Out: Analogue / Digital |
2 / No |
| Multichannel Pre-Out |
Yes (17.4 RCA & 17.4 XLR) |
| Subwoofer Out |
4 (independent) |
| Speaker A / B |
Assignable Pre-Out |
| Bi-Amp Drive |
Assignable Pre-Out |
| Multi-Room Speaker Terminal |
Pre-Out |
| Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB |
No / No / No / No / Yes |
| USB Audio / Made for iPod / Made for iPhone |
Yes / No / No |
| AM/FM Tuner |
Yes |
`
| General |
| Metal Front Panel |
Yes |
| System Remote Control |
RC-047SR |
| Pre-Programmed / Learnable / LCD Display |
Yes / Yes / Yes |
| Power Consumption |
100 W |
| Standby Consumption |
0.2 W |
| CEC Standby Consumption |
0.5 W |
| Network Standby Consumption |
Less than 2.0 W |
| Dimensions with Antenna: Horizontal (W x D x H) |
442 x 503 x 189 mm |
| Dimensions with Antenna: Vertical (W x D x H) |
442 x 503 x 252 mm |
| Dimensions without Antenna (W x D x H) |
442 x 480 x 189 mm |
| Weight |
16.8 kg |
