KEF Reference 5 Meta 3-Way 5-Drivers Floorstanding Speakers
DESCRIPTION
The benchmark of HiFi speakers
The flagship of The Reference Series is the model that all other high-performance loudspeakers compare themselves against. Now with the extraordinarily capable 12th generation Uni-Q®driver array with MAT™, Reference 5 Meta exemplifies the passion for innovation that underpins KEF’s design philosophy.
SPECIFICATIONS
Design
Three-way bass reflex
Drive units
Uni-Q driver array:
HF: 25 mm (1 in.) aluminium dome with MAT
MF: 125 mm (5 in.) aluminium cone
Bass units:
LF: 4 x 165 mm (6.5 in.) aluminium cone
Frequency range free field (-6dB)
Short port: 35Hz -45kHz
Long port: 32Hz - 45kHz
Frequency range typical in room bass response (-6dB)
25Hz
Frequency response (±3dB)
40Hz – 35kHz
Crossover frequency
450 Hz, 2.1 kHz
Amplifier requirements
50 - 400W
Sensitivity (2.83V/1m)
88dB
Harmonic distortion 2nd & 3rd harmonics (90dB, 1m)
<0.5% 40Hz – 100kHz
<0.2% 200Hz – 2kHz
<0.1% 2kHz - 20kHz
Maximum output (peak sound pressure level at 1m with pink noise)
116dB
Impedance
4 Ω
Weight
60.2 kg
Dimensions (H x W x D)(with grille and terminal)
1350 x 205 x 462 mm
Dimensions (H x W x D)(with grille, terminal & plinth)
1402 x 323 x 467 mm
