Description
Product Overview
Highlights The Stage Architectural Series was designed to deliver iconic JBL sound that blends into the environment so that the music stands out. All models are crafted to be visually discrete with zero bezel grilles and easy installation allowing these speakers to be heard and not seen. Elements including baffles with acoustic smoothing, acoustic lens tweeters, and some models with patented High- Definition Imaging (HDI) horns have been incorporated into the design to ensure that the sound is clear and accurate. A range of eight models are available in various configurations for In-Wall and In-Ceiling installation.
Highlights
Rigid Baffle design with acoustic smoothing for improved transducer integration
Aluminium Dome Tweeters with Acoustic Lens for smooth on and off axis frequency response
Harman target curve acoustic performance for smooth accurate sound over a large listening area
Zero bezel metal grille installs flush to wall or ceiling for clean inconspicuous appearance
XL-2 installation system compatible with up to 2” (50mm) thick wall/ceiling material
Specifications
High Frequency Transducer: 1" (25mm) Aluminium dome w/ Acoustic Lens
Low Frequency Transducer: 6.5" (165mm) Polycellulose cone woofer
Recommended Amplifier Power: 20-100W RMS
Frequency Response: 50Hz-25kHz (-6dB on-axis)
Sensitivity (2.83V@1m): 87dB
Nominal Impedance: 8ohm
Crossover Frequency: 3,000Hz
Inputs: Nickel-plated spring-loaded connectors
Grille Dimensions Dia: 239mm
Cutout Dimensions: 203mm
Mounting Depth: 101mm
Product Weight (Kg): 1.9Kg
Shipping Carton Dimensions: 280mm x W: 280mm x D: 136mm
Shipping Carton Weight: 2.54Kg
Price is per piece
