MAIN FEATURES
INTEGRATED AMPLIFIER Stereo - Class AB 90W @8Ω 140W@ 4Ω
Mono - 280w@8Ω
PHONO STAGE No Phono Stage
DAC AKM AK4493 BurrBrown PCM1796
Frequency Response 5Hz-50 kHz (+/- 3dB)
THD 0.001% (1KHz @1W)
SIGNAL TO NOISE RATIO >125dB
DYNAMIC RANGE 120DB
DSD DSD64
NETWORK CONNECTIVITY LAN & Wi-Fi 802.11a/b/g/n/ac Dual Band (10/433Mbps) Bluetooth High-Definition 5.0 (44/16)
HIGH-QUALITY STREAMING Roon Ready, Tidal Connect, MQA, Airplay, vTuner, Tidal, Qobuz, Deezer, Spotify Connect
SUPPORTED MEDIA SERVERS All UPnP DLNP ROON
SUPPORTED AUDIO FORMATS PCM up to 32 bits/384kHz
DSD up to DSD256 (DSF, DFF)
AIFF (aif, aiff, aifc)
WAV (wav) packed/unpacked FLAC
WmA Windows media Audio 9
WAX Windows media audio metafiles
ASX Advanced Stream Redirector (asx)
MPEG-4 (aac, m4a , Apple lossless)
MP3
IMPORTANT UPnP server must support DSD streaming in order to stream DSD files.
INPUTS AND OUTPUTS
DIGITAL INPUTS 1x RCA Coax PCM up to 24bit/192kHz
2x Optical Tos-Link PCM up to 24bit/192kHz
1x USB-A port DSD64 and PCM up to 24bit/192kHz, formatted in FAT32/NTFS (32Gb max for pen drives)
ANALOGUE INPUTS 2x RCA
ANALOGUE OUTPUTS Preamp
1x headphone output with 6.3mm jack
Mono Right 1x RCA single connector
POWER SUPPLY 100-240V, 50/60Hz
POWER CONSUMPTION <1W (standby)
FUSE (240V) 5A T
DIMENSION & WEIGHT
DIMENSIONS 200mm W, 80mm H, 260mm D
WEIGHT(Kgs) 4 – net
5 – boxed
FINISHES BLACK, GOLD, SILVER
