The new Bowers & Wilkins 702 S3 floor standing speaker's Carbon Dome tweeter is housed in an all-new solid body tweeter assembly, while with its new downward firing port configuration and trio of Aerofoil Profile bass cones, delivers bass that's both profoundly deep and endlessly articulate.
Description:
- 3-Way vented-box Floor Standing Speaker System
- Technical features
- Decoupled Carbon Dome tweeter
- Solid Body Tweeter-on-Top
- ContinuumTM cone FSTTM midrange
- Decoupled midrange
- AerofoilTM Profile bass cones
- Down firing FlowportTM
Drive units
- 1x ø25mm (1in) Decoupled Carbon Dome high-frequency
- 1x ø150mm (6in) Continuum cone FST midrange
- 2x ø165mm (6.5in) Aerofoil Profile bass
Key Specifications
- Frequency range 30Hz to 33kHz
- Frequency response (+/-3dB from reference axis) 46Hz - 28kHz Sensitivity(on axis at 2.83Vrms at 1m) 90dB
- Harmonic distortion 2nd and 3rd harmonics (90dB, 1m on axis) <1% 90Hz - 22kHz <0.5% 120Hz - 20kHz
- Nominal impedance 8Ω (minimum 3.1Ω Recommended amplifier power
- 30W - 200W into 8Ω on unclipped programme
Dimensions
- Height: 1010mm cabinet only. 1117mm including tweeter and plinth
- Width: 192mm cabinet only. 290mm including plinth
- Depth: 316mm cabinet only. 353mm including grille and terminals. 372mm including plinth
Net Weight
